How to set the parameter value of automatic winding machine

With the rapid development of the winding machine industry, manual semi-automatic equipment will slowly be eliminated, automatic winding machine as a fully intelligent machinery and equipment, many motor manufacturers began to use, although the operation is relatively simple, are automated, but for the parameters of the setup is still very important, the specific parameters involved? To introduce the following:

1, start winding position

The position of the skeleton to start winding, and the coil out and type of a certain relationship, you can use the winding machine control system to measure the specific value of the start winding, of course, can also be measured manually, to a fixed point as a point of reference, the use of rulers, pay attention to the direction of the coil winding is not the right one.

2, winding width

winding width refers to the start of the winding point to the end of the point location distance, generally is the length of the skeleton winding. In the process of setting, to consider the influence of the skeleton subtle deformation, can take the small value as the winding width through the comprehensive measurement.

3, enameled wire

enameled wire has many kinds of specifications, if not properly set up will affect the effect of the winding line. Then the enameled wire material is not the same, the correction value is not the same, like the copper wire is more fine hard material, the correction value of 0.02 or so; like the aluminum wire is relatively soft and easy to stretch, the general correction value of 0.02-0.2 between.

The above is the automatic winding machine some common parameter settings, master the debugging methods and principles, in order to better wind the coil.
