Automatic Multi-slot Stator Internal Winding Machine

Automatic Multi-slot Stator Internal Winding Machine

Only manual feeding, the machine can automatically complete a series of operations such as clamping molds, winding, pulling the head, clamping the line, cutting the line and so on, which reduces the labor intensity of manpower and greatly improves the production efficiency.

• Stator specifications: the stator inner diameter, outer diameter, stack thickness and other parameters can be wound in a certain range, such as the stator inner diameter is generally φ15mm or more, the outer diameter of ≤ Φ140mm, the stack thickness range of 5-100mm, etc., the specific specifications vary depending on the model of the equipment.




• Winding speed: the adjustment range is usually around 0-380rpm, some high-speed equipment can have higher winding speed, which can be adjusted according to the material of the stator, wire diameter and the requirements of the winding process.




• Flexible parameter setting: the number of stator slots, the number of turns, the winding speed, the number of taps and other parameters can be set through the human-machine interface, and you can quickly switch between different stator and winding parameters, in order to adapt to the production requirements of different stators.




• Troubleshooting and protection: with troubleshooting function, when a fault occurs, it can automatically display the fault information and processing methods on the screen, which is convenient for maintenance and debugging; at the same time, it has a self-protection device, even if the operator misoperation will not cause serious damage to the machine.




• Good protective performance: usually use all aluminum alloy (anodic oxidation treatment) and imported acrylic protection, or aluminum alloy profile assembly frame, beautiful appearance, can effectively prevent the operator from electric shock and equipment by the outside environment
