The following is a summary of common mechanical failures and solutions for brushless motor manual stator slot wedge machine:

Brushless motor manual stator slot wedge machine common mechanical failures and solutions

First, the common mechanical failure

1, transmission mechanism stagnation or wear

Phenomenon: handle rotation difficulties, gear / belt slippage, noise increase.

Reason: insufficient lubrication, gear wear, belt aging or improper tightening.

Solution:

Clean and add grease (e.g. lithium grease) regularly.

Replace worn gears or aging belt, adjust the belt tightness.

2, pressure mechanism failure

Phenomenon: The slot wedge is inserted insufficiently or too violently, resulting in damage to the stator slot.

Cause: Spring fatigue, air / hydraulic system leakage / oil leakage.

Solution:

Replace the spring that has failed elastically.

Check the seals and repair air/oil leaks.

3. Positioning deviation

Phenomenon: The slot wedge insertion position is deviated, resulting in an untidy stator winding.

Cause: Loose fixture, worn positioning pin, deformed guide rail.

Solution:

Tighten the fixture screws and replace the worn positioning pins.

Correct or replace the deformed guide rail.

4、Deformation or wear of guide parts

Phenomenon: The slot wedge insertion path is skewed, jamming frequently.

Reason: Long-term force leads to deformation of the guide bar / guide rail or surface wear.

Solution:

Use a micrometer to correct the straightness of the guide parts.

Replace the guide parts with high hardness material (e.g. chrome-plated steel) in case of serious wear.

5、Loose fasteners

Phenomenon: The whole equipment shakes when running, affecting the accuracy.

Reason: Screws and nuts are not regularly checked, and vibration causes loosening.

Solution:

Regularly check and tighten the screws of each connection part.

Use thread adhesive or spring washers in key parts to prevent loosening.

Second, preventive maintenance recommendations

1、Daily maintenance:

Clean the equipment after daily use, clear away iron filings and dust.

Lubricate the transmission parts (gears, chains) once a week.

2、Regular calibration:

Check the positioning fixture and guiding accuracy every month, and adjust if necessary.

Quarterly calibration of the pressure mechanism output force is up to standard.

※ If through the above ways and means still can not solve the equipment failure, please contact Xinhui Electromechanical Equipment Co., Ltd. through the page chat tool to seek help from the technical specialist.
